Grain bin monitoring

GrainLink watches stored grain with more than 1 000 systems built on CHESTER

GrainLink gives farmers in Canada and the USA a view into their grain bins and runs the aeration for them. We adapted CHESTER for it, and eight months after the first contact the solution was validated.

CHESTER GrainLink unit with its solar panel on a bin railing above a snowy farmyard
A CHESTER GrainLink unit on the railing of a grain bin in winter. Photo: GrainLink.

1 000+

systems in Canada and the USA

8 months

from contact to validation

2026

the next generation ordered

The situation

Grain stays in steel bins for months after the harvest. Heat and moisture can build up deep inside, where nobody sees them until the grain spoils. According to GrainLink, whole bins have had to be emptied and thrown away.

GrainLink measures the grain from the inside. Sensor cables hang through each bin, and the readings reach the farmer wherever they are. The same data automates the aeration of each bin.

What we delivered

Each GrainLink unit is our CHESTER on a carrier board we designed for GrainLink, with firmware and an enclosure made for life on a bin roof. It reads up to 150 temperature sensors on 1-Wire cables and reports over LTE-M. A small solar panel charges its battery, so a bin needs no power line. HARDWARIO Cloud passes the data to the GrainLink web app.

We developed it with Axilera, GrainLink’s technology partner, and tested it in the climatic chamber of our workshop in Liberec. The design is ours, adapted for GrainLink, which is how we work with every customer whose use case runs on our devices.

Eight months, then a thousand systems

Eight months after the first contact the solution was validated. The first series of 500 systems followed in 2024 and the second in 2025, for farms in Canada and the USA. Each unit is rated from −30 to +70 °C and works through the winter on bin roofs and catwalks.

The next generation

In 2026 GrainLink ordered its next generation from us: four new platforms, from prototypes to a pre-series.

GrainLink enclosure covered in hoar frost on the railing of a snowy bin catwalk
Hoar frost on a unit along a bin catwalk.
Opened CHESTER GrainLink unit wired to the sensor cables of a bin, a hand-drawn cable map beside it
An opened unit wired to the sensor cables of a bin.
