CHESTER
Push

Configurable NB-IoT/LTE-M/LoRaWAN device with four buttons for instant message sending when pressed.

CHESTER Push catalog application allows to setup device with up to 4 independent buttons that instantly publishes the presses to cloud for notification and state reporting.

Showcase of CHESTER Push catalog application. It shows a possible placement and a dashboard
4 durable buttons
with LED indication

On the front of the device are four durable buttons with LED indications for immediate feedback to the user. Actions can be marked with a customizable printed enclosure.

Short and long press,
or a toggle switch?

You can operate the device in two modes. The first distinguishes between the short and long press and the second works as a state switch.

Instant message sending
by wireless connection

The device runs from the mains with a backup battery and, immediately after pressing, transfers data over cellular networks (NB-IoT / LTE-M) or public/private LoRaWAN networks.

Fast deployment and
seamless integration

Use the HARDWARIO Manager iOS/Android app to set the behavior of each input and integrate its data from HARDWARIO Cloud.

Application areas

Typical use cases

You can utilize CHESTER Push as an ANDON system and thus enable your workers to instantly report production line problems.

By using the data acquired from the specific use of the device, you can track the utility of each production or assembly line.

In all the possible applications, CHESTER Push is the key for the significant reduction of the overall production downtime.

Capabilities

Product overview

Enclosed CHESTER Push in the standart variant with four buttons on the enclosure

Application elasticity

One modular device covering a wide spectrum of IoT projects.

Open source SDK

Ability to create your applications or update the existing ones.

LPWAN connectivity

Communication to the internet from the most distant places.

Low-power design

Reliable operation from a primary cell battery for several years.

IP 67 protection level

Enclosure to withstand harsh environmental conditions.

Custom branding

Full OEM branding service, including custom color printing.

Bluetooth Low Energy

For diagnostics, parametrization, and device firmware upgrades.

Truly configurable device

One CHESTER for so many configurations

The CHESTER platform goes way beyond one specific application use case. The system design, integrated hardware technologies, firmware architecture, and the ecosystem of tools - all of this scales well to a wide range of applications - from Industry 4.0, smart city, e-metering, and environmental monitoring to some very special verticals such as digital retail and agriculture.

CHESTER Mainboard without the case with many point showing each part of the board
Details

Technical specifications

Open CHESTER case showing the internals with the CHESTER mainboard and expansion module CHESTER Z that allows external power suply

Number of ALU buttons

4

Power supply method

Mains + backup battery

Open CHESTER case showing the internals with the CHESTER mainboard and expansion module CHESTER Z that allows external power suply

Nominal backup battery voltage

3.7 V

Nominal backup battery capacity

3 350 mAh

Operating voltage range

2.0 V to 5.0 V

Idle power consumption

< 180 μA

Peak power consumption

< 250 mA

Operating temperature range

-30 to +70 °C

Storage temperature range

-40 to +85 °C

Dimensions

130×175×45 mm

Deployment

Easy setup and configuration

Our catalog applications are made to be setup simply and quickly. After you choose your application and get your package, just install CHESTER in the desired location, register it to our cloud and you will get the data to your dashboard that is created based on the selected application.

Example dashboard for catalog application
Simple three step flow showing how easy is it to setup and operate CHESTER
The right choice

Get CHESTER

Choose one of the catalog applications for immediate deployment, or contact us with your specific needs. Get in touch with us to learn more and build IoT projects for your customers today, together.

CHESTER ecosystem, showing all the extensions, expansion boards, enclosures and external sensors
